Posted By admin On 07.10.19The Caterpillar Digital Voltage Regulator (CDVR) is a microprocessor based voltage regulator. The main purpose of a digital voltage regulator is to regulate the output voltage of a generator that is used with an engine generator set. Control power for the Digital Voltage Regulator is supplied from an external 24 DCV source. The power stage of the Digital Voltage Regulator can be supplied from a multi-pole, high frequency, permanent magnet generator (PMG),from the generator output (shunt excitation), or from auxiliary windings that are included on some generators.
Cat Dvr Manual
Cat® XQ425 Rental Generator Set LEHE1123-00 Page 1 of 8. •O&M manuals Optional Equipment Available Options. • Integration with the Cat DVR provides enhanced system monitoring • Ability to view and reset diagnostics of all controls networked on primary CAN data link eliminates need for separate service tools for troubleshooting.
Cat Dvr Manual Pdf
Dvr User Manual
Connections to the Digital Voltage Regulator are made through three multi-pin, plug type connectors. The communication between the Digital Voltage Regulator and a service tool is accomplished using a CANBUS protocol.
